Vsd Intern - Dac Ip Design Using Sky130 Pdks - Part 1

[LeeAndro]

Last updated 5/2021MP4 | Video: h264, 1280x720 | Audio: AAC, 44.1 KHzLanguage: English | Size: 704.25 MB | Duration: 1h 45m

Overview of DAC Theory, Circuit and project flow

What you'll learn
Overview of DAC
Background and Principle of Operation
Implementation Aspects and Challenges
Evaluation Parameters
Expected Input Output Characteristics

Requirements
VSD - Circuit Design and SPICE simulations
VSD - Custom Layout
VSD Intern - Bandgap IP Design

Description
The webinar aims to design a 10-bit potentiometric Digital to Analog Converter using end-to-end Open-source EDA tools.​

The target is to design 10-bit potentiometric DAC with 3.3v analog voltage, 1.8v digital voltage and 1 off-chip external voltage reference using sky130nm technology node.In real world, most of the data available is in the form of analog in nature. We have two types of converters analog to digital converter and digital to analog converter. These two converting interfaces are essential to obtain the required operations of a processor to manipulate the data of digital electronic equipment and an analog electric equipment. Digital to Analog Converter (DAC) is a device that transforms digital data into an analog signal in order to interact with the real world. The digital signal is represented with a binary code, which is a combination of bits 0's and 1's. The digital data can be produced from a microprocessor, Field Programmable Gate Array (FPGA), or Application Specified Integrated Circuit (ASIC). There are two commonly used DAC conversions - Weighed resistors method and R-2R ladder network method. Applications of a DAC: audio amplifier, video encoder, display electronics, data acquisition systems, calibration, Digital potentiometer.This webinar will cover1) Overview of DACWhy DACBackground and Principle of Operation.Implementation Aspects and Challenges.Evaluation Parameters.2) Project Design Specs and DAC CircuitCircuit BehaviourExpected Input Output Characteristics.3) Project Flow -Analog IP - Hands-onFlow of Steps for Analog IP design.Tools RequiredSetup of ToolsLibraries Requirede) Setup and linking Libraries.All the best and happy learning

Overview
Section 1: Introduction and DAC Overview

Lecture 1 Introduction To DAC Project And Applications

Lecture 2 Background And Principle Of Operation

Lecture 3 Reference Voltage Resolution And Linearity Aspects Of DAC

Lecture 4 Monotonicity, Settling And Speed Of DAC

Section 2: DAC Specs, Implementation Aspects and Challenges

Lecture 5 DAC Architectures, Applications, Decoding Method And Switching Network

Lecture 6 DAC Non-Linearity And Output Voltage Level Parameters

Lecture 7 DAC Interface Specs And Operating Modes

Lecture 8 DAC DNL and INL Specs

Section 3: 10-bit DAC Implementation strategy

Lecture 9 Fundamental DAC Circuit

Lecture 10 10-bit DAC Implementation Strategy - Divide And Conquer

Lecture 11 From 2-bit DAC to10-bit DAC

Section 4: Tool Setup steps

Lecture 12 Detailed Steps To Install Latest NGSpice From Scratch

Lecture 13 Detailed Steps To Install And Configure Magic With Sky130 PDKs

Lecture 14 Detailed Steps To Install And Configure Xshem With Sky130PDKs

Lecture 15 Simple Inverter Design Using Xschem And Sky130 Models to confirm tool install

Lecture 16 Simple Pre-Layout Simulation Steps Using NGSpice

Section 5: Conclusion

Lecture 17 Conclusion

Curious freshers looking to enter into analog and mixed-signal VLSI design,Bner or Professional Physical Design Eeers looking to know more about IPs and Macros

HomePage:

https://www.udemy.com/course/vsd-intern-dac-ip-design-using-sky130-pdks-part-1/

DOWNLOAD

https://1dl.net/lfz24b9d8yn2/Cb27DcXd__VSD_Intern.rar
