ANSYS Explicit Dynamics: Droptest simulation of a Barrel

[LeeAndro]

Published 12/2022Created by Herk DanielMP4 | Video: h264, 1280x720 | Audio: AAC, 44.1 KHz, 2 ChGenre: eLearning | Language: English | Duration: 9 Lectures ( 37m ) | Size: 470.5 MB

Create a geometry for a droptest in SpaceClaim
Prepare the geometry with Workbench
Create mesh, set up symmetry and body interactions
Basic solver setup for a droptest
Define boundaries and initial conditions
Post-processing: evaluate your simulation

Software is recommended.​

You can the Student Version from the ANSYS website (Google -> ANSYS Student)
Experience with FEM Simulations and Eeering knowledge recommended, but nut mandatory

In this class I am going to show you a really simple Droptest with an empty barrel. This is a step by step tutorial and is recommended for everyone with desire to simulate falling objects.As a bner compatible course, it contains only the necessary elements and steps, to be as straightforward as possible. The goal is to learn the essential structure and workflow of a droptest simulation and not to confuse the newcomers. In future, more advanced courses we are going to expand the limits and possibilities of our simulation and include the following, not yet applied skills like:- set up parametrized workflow- include material with failure model- solve problems, where bodies are breaking/fracturing- include liquids with Euler/ALE  methods- include explosions and pressure wavesThis is the first part of the course-serie, a nice basis to start from.You do not require any experience with ANSYS, but explicit dynamics is an advanced field. If you have any questions, don't be shy to ask anything.As project or self-practice you can make a modified version of our droptest with a little twist here and there. Modify the Dimensions, drop height or the material properties as you like to see the influence at the end.This is going to be a good practice to see, if you have a good understanding of a basic droptest.

Intended for bners in the Explicit Dynamics simulation environment
Intended for everyone who wants to learn the basics of a Droptest
